IFC to 3DS Conversion
Here’s a list of valuable resources, packed with detailed instructions and expert tips for converting IFC files to 3DS format using our converters. Peruse them now to make your IFC files conversion process smoother later.
- Convert 3D Mesh Files in the Batch Mode
- STEP File Converter to Mesh File Formats
- Explode Component Instances into Mesh Groups
- Automesher Desktop Application for Windows to Convert 3D File Formats
- Autoconverter Uses Vertex Normals to Display Smooth Meshes
IFC vs 3DS Comparison
| Property | IFC | 3DS |
|---|---|---|
| Extensions | .ifc | .3ds |
| Name | Industry Foundation Classes | 3D-Studio File Format |
| Versions |
|
|
| Textures | ||
| Colors | ||
| Geometry components |
Industrial Foundation Classes File
A file format that is widely used in the AEC (Architecture Engineering Construction) industry. It is supported by many software applications, such as Revit from Autodesk or SmartPlant 3D by Intergraph. IFC can store various types of information related to AEC projects, such as:
- Geometry: IFC can represent the shape and size of 3D models, using different types of entities such as solids, surfaces, curves, or points.
- Units: IFC can specify the measurement units for each 3D model, such as meters, inches, degrees, or radians.
- Materials: IFC can define the color and transparency of each geometry component, using values from 0 to 1 for red, green, blue, and alpha channels.
- Instances: IFC can reuse the same geometry component multiple times, by creating mapped items that refer to the original shape definition. This can save storage space and improve performance.
- Structure: IFC can organize the 3D models into a hierarchical structure, using names and identifiers for each component. This can help to manage complex projects and facilitate collaboration.
- BIM: IFC can include generic BIM (Building Information Modeling) data, such as properties, attributes, relationships, or constraints for each 3D model. This can enhance the functionality and interoperability of the file format.
IFC File Converters: Autoconverter and Automesher Application are compatible with IFC, and you can use them to import and export IFC models. You can also modify the custom properties of the IFC geometries, and convert them to other 3D file formats. However, please note that some features of IFC may not be supported by other file formats, and may be lost during the conversion.
3D Studio File
A widely recognized format used for storing polygonal mesh models. It has gained popularity due to its extensive feature set and compatibility with various software, such as:
- Extensive Support: The 3DS format supports a variety of features including model names, reusable geometry component instances, materials with transparent colors, and texture images.
- Compatibility: You can import and export 3DS models to and from many software applications, such as DIALux, which is used for lighting design.
- Legacy Constraints: Due to its legacy constraints, 3DS model names are limited to 8 characters. Additionally, a single 3DS mesh object can only contain up to 32,767 triangles.
3DS File Converters: To overcome legacy limitations and convert any mesh into 3DS format, you can use our Autoconverter and Automesher Application. They will automatically split your models into smaller shells to accommodate the triangles limit, and convert them to the 3DS format.
